- Model NO.: FV40B+C/3-150 (S)
- Installation: Parallel Arrester
- Size: Small
- Certification: ROHS, ISO9001, CE
- Color: Gray
- Speed: <25ns
- No. of Poles: 3 Poles
- Uc: 150V AC
- Housing material: UL94V0
- Trademark: FATECH, OEM is welcome
- Specification: CE
- HS Code: 85363000
- Type: Power Source Arrester
- Application: AC/DC System
- Operation Voltage: Low Voltage
- Brand: FATECH
- Protection Mode: L1, L2, L3-PE
- Function: Surge Protection for Power System in AC Side
- OEM&ODM: Welcome
- Protection level: Class 1+2 protection
- Imax: 80ka
- Transport Package: 1 PC Surge Arrester in One Inner Box
- Origin: China
AC SPD FV40B+C/3-150(S) is for low-voltage power supply 150V, Imax 80kA, 3poles.
Â
1. AC surge arrester for low-voltage power system CharacteristicÂ
- Class I+II surge protective device onsisting of a base part and MOV plug-in protection modules.
-High energy MOV inside.
-Low residual voltage and quick response.
-Reliable control thanks to Thermo Dynamic Control disconnector.
-With remote signaling contact for control device.
-Fault indication via red mark in the inspection window.
-Protection mode: L1, L2, L3-PE.
2.  AC surge arrester for  low-voltage power  system Dimension and Circuit  FV40B+C/3-150(S)

 Â
3. AC surge arrester  for low-voltage power system Certificate
Our global partners:
We are now exporting more than 100 countries and areas, mainly in Europe, Asia, Latin-America, and Middle East. Our global partner including- Ericsson
- Sri Lanka Telecom
- Telefonica-Movie
If you are interested in ,please feel free contact to me!
| Â Model No.: FV40B+C/3-150(S) | Â | Â | Â |
|  Max. continuous AC voltage |  Uc |  V | 150 |
| Â Requirement class to DIN EN 61643-1: 2005 | Â | Â | Â Class B+C |
|  Nominal Discharge current(8/20μ s) |  In |  kA |  40 |
|  Max. discharge current (8/20μ s) |  Imax |  kA |  80 |
| Â Voltage protection level (at In)Â | Â Up | Â kV | Â <=1.5 |
| Â Response time | Â tA | Â ns | Â 25 |
| Â Operation temperature range | Â | Â | Â Â -40 ~ +85degree |
| Â Degree of protection | Â | Â | Â IP20 |
| Â Remote control contacts | Â | Â | Â Optional |
